X5 Aluminum Veneer Cutting Carving CNC Router

Short Description:

Building decoration materials, kitchenware and bathroom, elevator manufacturing, household appliances, machinery and equipment, mold processing, decorative advertising, shipbuilding, aerospace manufacturing and other machinery manufacturing and processing industries.


Product Detail

Product Tags

Overview

Condition:New
Range of Spindle Speed(r.p.m):1 - 24000 rpm
Positioning Accuracy (mm):0.01mm
Number of Axes:3
No. of Spindles:Single
Working Table Size(mm):2000×4000
Machine Type:CNC Router
Travel (X Axis)(mm):2000mm
Travel (Y Axis)(mm):4000 mm
Repeatability (X/Y/Z) (mm):0.01 mm
Spindle Motor Power(kW):6
CNC or Not:CNC
Place of Origin:Zhejiang, China
Brand Name:GXUCNC
Voltage:380V/50HZ
Dimension(L*W*H):3.05m*2.1m*1.85m
Power (kW):8
Weight (KG):3500

Control System Brand:Syntec
Warranty:2 years
Key Selling Points:High Rigidity
Applicable Industries:Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Restaurant, Home Use, Retail, Construction works , Energy & Mining, Advertising Company
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Warranty of core components:2 years
Core Components:Motor
Product name:Cnc Router Engraving Machine
Working area:2000*4000
Total Spindle Power:6kw
Power Supply:380V/50HZ
Processing accuracy:0.01mm
Drive motor:Servo
N.W:3500KG
After-sales Service:Online suppor

Machine datails

Product Size

4925*3035*2000mm

Positioning method

Cylinder positioning

Model

X5

Spindle speed

24000rpm/min

Processing speed

12000mm/min

Plate fixing method

Press wheel device + cylinder

Maximum feed height

200mm

Oil filling method

Automatic

Empty travel speed

45000mm/min

Spindle

7.5KW Mould Quiet Spindle

Transmission method

XY25 linear guide

Net weight

4500KG

Application areas

Building decoration materials, kitchenware and bathroom, elevator manufacturing, household appliances, machinery and equipment, mold processing, decorative advertising, shipbuilding, aerospace manufacturing and other machinery manufacturing and processing industries

Machine features

1.  Industrial heavy-duty bed, tempering, five-axis machining center machine finishing.

2. Adopt Taiwan brand linear guide, German brand precision helical gear, Japanese planetary reducer, high torque AC servo motor motor.

3.  Precision high-power variable frequency constant power and constant torque spindle can realize long-term stable high-speed processing. It can be equipped with automatic tool change, dual-spindle, triple-spindle switching high-speed blanking, punching code holes, card slots and other functions. Reduce equipment cost input and save equipment input cost.

4.  The powerful control system adds the function of automatic programming-free system: It eliminates complicated programming steps, only needs to import CAD drawings into the control system, and it can be produced through simple settings, which reduces the requirements for operators and facilitates personnel recruitment.

5.Professional automatic avoidance fixtures make the plate utilization rate higher. The double-roller platen system can realize the simultaneous cutting of multi-layer plates, which increases the processing efficiency.

1
2
3
7
6

Support Door to Door

1. 24/7 online service .

2. 2 years warranty for machine.

3. After sale office in differ country

4. Life time maintenance

5. Free online technical support and install train.

6. We have a professional and experienced after-sales team.

7. We support door-to-door after-sales service.

8. In order to effectivelysolve customer problems and help customers use the machine better, we will conduct skill assessments on our after-sales team every year.
